Phantom R

The Phantom R is only available in Europe at this stage.The Phantom R is a gravel’s apex predator. Building on the X’s foundation, it adds a SRAM Rudy suspension fork (40mm travel) and Reverb AXS dropper post to dominate chunky descents and rock gardens. The monolith frame’s reinforced junctions handle suspension loads, while the Avinox system’s Boost mode provides explosive 120 Nm torque for steep, loose climbs. Wide 45c tires, and a 600Wh battery make it a self-sufficient beast for multi-day bikepacking races or back-country missions. This is the bike for riders who want it all.

Expected delivery: July 2026
Price
€8.999,00 EUR
€8.999,00 EUR
Size
Carbon Fibre Monocoque Frame
SRAM Rival E1 13-speed Electric Shifter
8 Mounting Points on Frame &
6 Mounting Points on Fork for Bike Packing
Warranty: Frame 5-Years | Avinox Drive System 2-Years

Specifications

  • Frame: Carbon fibre, gravel category, battery integrated, inner cable routing, 12X142mm, 8 mounting points, rack compatible
  • Fork: Rockshox Rudy ULT 40mm travel700 U GLB 41T A2
  • Headset: FSA NO.55R 1.5" / 558 ACR, Alloy gravel, dia top& bottom 52mm
  • Stem: FSA SMR Alloy -6° alloy Length S:70mm M:80mm, L:90mm, XL:100mm
  • Saddle: Fizik Terra Aidon X5
  • Seatpost: Rockshox Reverb AXS XPLR 27.250mm travel, 400mm length
  • Handlebar: Velduro Carbon, Dia31.8, Flare 15°, Width: S/M 420mm, L/XL: 440mm
  • Straps: Velduro black gravel strap
  • Motor: Avinox M2 36V 1100W / 110Nm, boost to 125Nm.
  • Battery: Avinox 600Wh integrated.
  • Display: Avniox DP100 integrated 2-inch display.
  • Button: Avinox BC100 Wireless control left&right.
  • Charger: Avinox 4A charger.
  • Cables: Avinox customised Waterproof and foolproof wiring.
  • Brakes: Sram Rival AXS HRD Shift-Brake System
  • Discs: Sram HS2 extreme duty disc, front 160mm, rear 160mm
  • Rear derailleur: Sram Rival XPLR AXS Rear Derailleur with power cable
  • Cassette: Sram Rival XPLR XG-1351 13-speed Cassette
  • Cranks: Avinox SL 165mm
  • Chain: Sram Rival Transmission Flattop Chain
  • Spider: Avinox 104BCD spider
  • Chainwheel: Velduro customized alloy 44T, 3mm inward
  • Wheelset: Easton EC70 AX carbon gravel wheels, 24mm inner width, 21mm depth, XDR freehub
  • Tires: Maxxis Rambler 700*45C BLK, with tube

* Your Phantom is tubeless-ready, but comes with a tube.

Phantom Features

  • Full Carbon Monocoque Frame

    Award-winning ultra-lightweight carbon monocoque frame.

  • Avinox High Torque Motor

    The Phantom is powered by the market-leading Avinox M2 lightweight drive system with up to 1100W / 125Nm torque in boost and 110Nm of continuous torque.

  • Multi-function Customizable OLED Touch Screen

    Connectivity between motor and mobile.

Phantom Geometry

S M L XL
A Seattube Length (mm) 466 486 506 526
B Top Tube Horizontal (mm) 520 534 551 565
C Toptube Length (mm) 495 515 534 548
D Head Tube Angle (°) 70 70,5 71 71
E Seattube Angle (°) 74,4 74,1 73,6 73,6
F Standover (mm) 772 785 815 830
G Head Tube Length (mm) 135 147 159 179
H Wheelbase (mm) 1015 1019 1030 1040
I Front Center (mm) 600 605 606 620
J Chain Stay Length (mm) 425 425 430 430
K Bottom Bracket Drop (mm) 72,5 72,5 72,5 72,5
L Bottom Bracket Height (mm) 283 283 283 283
M Fork Rake (mm) 50 50 50 50
N Trail (mm) 64 63 63 63
O Stack (mm) 554 567 581 600
P Reach (mm) 366 372 377 385
Q Axle to Crown (mm) 395 395 395 395
Recommended height (cm) 160-170 172-182 180-188 185-195
